5X - Setting Up GitHub Merge-Triggered Workflows Using 5X Webhooks

This guide explains how to configure your GitHub repository to automatically trigger 5X workflows/jobs when code is merged into the main branch or other specific branches.

Overview

5X workflows can be triggered via webhooks, allowing seamless integration with GitHub events. When a webhook-triggered job is created in 5X, you'll receive a webhook URL and an access token that can be configured in your GitHub repository settings.

Note: Currently, each workflow can have only one trigger type (excluding manual triggers, which are always available). Additionally, the trigger type for a job cannot be currently edited once the job has been created. Support for multiple triggers per workflow as well as the ability to edit the trigger type for a job once created is coming soon.

Step-by-Step Configuration

1. Create a Webhook-Triggered Job in 5X

Navigate to the Jobs section in your 5X workspace

Create a new job

In the trigger configuration, select "Webhook" as the trigger type.

Add additional nodes as relevant to the job.

Save the job

Once the job is saved, copy the provided webhook URL and access token - you'll need these for GitHub setup

Setting Up GitHub Merge-Triggered Workflows Using 5X Webhooks

This guide explains how to configure your GitHub repository to automatically trigger 5X workflows when code is merged into the main branch.

Overview

5X workflows can be triggered via webhooks, allowing seamless integration with GitHub events. When a webhook-triggered job is created in 5X, you'll receive a webhook URL and an access token that will be used in GitHub Actions to trigger your workflows.

Note: Currently, each workflow can have only one trigger type (excluding manual triggers, which are always available). Support for multiple triggers per workflow is coming soon.

Step-by-Step Configuration

1. Create a Webhook-Triggered Job in 5X

Navigate to the Orchestration section in your 5X workspace

Create a new job or edit an existing one

In the trigger configuration, select "Webhook Trigger"

Save the job

Copy the provided webhook URL and access token - you'll need these for GitHub Actions setup

2. Set Up GitHub Actions Workflow

Create a new GitHub Actions workflow file at .github/workflows/trigger-5X-job.yml:

name: Trigger 5X Workflow

on:

pull_request:

types: [closed]

branches:

- main

jobs:

trigger-5x:

if: github.event.pull_request.merged == true

runs-on: ubuntu-latest

steps:

- name: Trigger 5X Webhook

run: |

curl -X POST \

-H "Authorization: ${{ secrets.FIVEX_WEBHOOK_TOKEN }}" \

-H "Content-Type: application/json" \

-d '{"event": "merge_to_main", "repository": "${{ github.repository }}"}' \

${{ secrets.FIVEX_WEBHOOK_URL }}

3. Set Up GitHub Secrets

In your GitHub repository, go to Settings → Secrets and variables → Actions

Add two new Repository secrets:

Name: FIVEX_WEBHOOK_URL Value: Your 5X webhook URL that was copied when the job was saved

Name: FIVEX_WEBHOOK_TOKEN Value: Your 5X access token that was copied when the job was saved

Verification

To verify your setup:

Create a pull request to your main branch

Merge the pull request

Check the GitHub Actions tab to confirm that an action was triggered

Verify in 5X that your job started executing

Troubleshooting

Verify the access token and webhook URL are properly set in GitHub secrets

Check GitHub Actions logs for any curl command errors

Confirm the workflow is properly configured in 5X to accept webhook triggers

For additional support, contact 5X support team support@5x.co.
