The component helps you to switch your content between tabs with icons
How to design it in Power Apps
Preview
What does it consist of?
Procedure
Step 1 - create boolean variable on Screen
When you create a new screen(or use already created) you should create a variable on "OnVisible" property:
Set(selTab,"P")
Step2- create HTML tab boxes
Add a new HTML TEXT object, call it "tab_box" with this "HTML text" property:
"<div style='margin:0px;width:"&Self.Width-5&"px;height:"&Self.Height-5&"px;background-color:#fff; border-radius:15px;'></div>"
Add a new HTML TEXT object, call it "tab_header" with this "HTML text" property:
"<div style='margin:0px;width:"&Self.Width-5&"px;height:"&Self.Height-5&"px;background-color:#fff; border-radius:30px 30px 10px 10px;'></div>"
and "X" property:
If(selTab = "P" || IsBlank(selTab),48,220)
Step 2 - add titles for tabs
Add a new TEXT PCF object, call it "profit_text" with this "text" property:
"Profit"
and "X" property:
If(selTab = "C",100, 119)
Add a new TEXT PCF object, call it "cost_text" with this "text" property:
"Cost"
and "X" property:
If(selTab = "P" || IsBlank(selTab),277,300)
Step 3 - add transparent buttons
Add a new Button PCF object, call it "profitbutton" with this "Appearance" property:
'ButtonCanvas.Appearance'.Transparent
and "X" property:
If(selTab = "C",95, 108)
Add a new Button PCF object, call it "costbutton" with this "Appearance" property:
'ButtonCanvas.Appearance'.Transparent
Step 4 - add icons for tabs
Add a new Image object, call it "profit_icon" with this "Image" property:
Add a new Image object, call it "cost_icon" with this "Image" property:
Step 5 - group all objects
Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).
This is an output:
How to design it in Figma
Preview
What does it consist of?
Procedure
Step 1 - create a tab header with content box
Add a new Rectangle (R command) object, call it "html_content_box" with these properties:
Add a new Rectangle (R command) object, call it "html_header_box" with these properties:
Step 2 - create icons with texts
Import a new SVG file, call it "svg_up_icon" with this XML code:
<svg width="37" height="37" viewBox="0 0 37 37" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M4.53592 25.7036L13.6078 16.6318L19.6557 22.6797L31.7515 10.5839" stroke="#292929" stroke-width="3.77994" stroke-linecap="round" stroke-linejoin="round"/>
<path d="M25.7036 10.5839H31.7515V16.6318" stroke="#292929" stroke-width="3.77994" stroke-linecap="round" stroke-linejoin="round"/>
</svg>
Import a new SVG file, call it "svg_down_icon" with this XML code:
<svg width="37" height="37" viewBox="0 0 37 37" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M4.53593 10.5839L13.6078 19.6557L19.6557 13.6078L31.7515 25.7036" stroke="#292929" stroke-width="3.77994" stroke-linecap="round" stroke-linejoin="round"/>
<path d="M25.7036 25.7036H31.7515V19.6557" stroke="#292929" stroke-width="3.77994" stroke-linecap="round" stroke-linejoin="round"/>
</svg>
Add a new Text (T command), call it "lbl_profit_title" with these properties:
Add a new Text (T command), call it "lbl_cost_title" with these properties:
Step 3 - group all objects
Select all objects and press COMMAND + G (MAC) or CTRL + G (WIN) and call the group "gr_tabs_group".
This is an output:
How to use it via DesignKit
Prerequisites
Used Prefixes
YAML Output
Used Colours
