Time Picker

MyCondy

Last edited 15 days ago by MyCondy

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

6x Container

6x Image

4x Label

Procedure

Step 0 - create boolean variable on Screen

When you create a new screen(or use already created) you should create a variable on "OnVisible" property:

Set(_hour_value,8);Set(_minute_value,10);Set(_day_value,"PM")

Step 1 - create cover container

Add a new Horizontal Container PCF object, call it "time_picker" with this "DropShadow" property:

DropShadow.Semibold

Step 2 - create time content container

Add a new Horizontal Container PCF object, call it "time_frame" with this "Gap" property:

Step 3 - create hour content container

Add a new Vertical Container PCF object, call it "hour_frame" with this "Gap" property:

Add a new Image object under "hour_frame", call it "hour_up_icon" with this "Image" property:


And "OnSelect" property:

Set(_hour_value,Value(hour_value.Text)+1)

And a new Label object under "hour_frame", call it "hour_value" with Text property:

Text(_hour_value,"00")

And a new Image object under "hour_frame", call it "hour_down_icon" with this "Image" property:


And "OnSelect" property:

Set(_hour_value,Value(hour_value.Text)-1)

Step 4 - create separator content container

Add a new Vertical Container PCF object, call it "sep_frame" with this "Gap" property:

And a new Label object under "sep_frame", call it "separator" with Text property:

":"

Step 5 - create minute content container

Add a new Vertical Container PCF object, call it "minute_frame" with this "Gap" property:

Add a new Image object under "minute_frame", call it "minute_up_icon" with this "Image" property:

And "OnSelect" property:

Set(_minute_value,Value(minute_value.Text)+1)

And a new Label object under "minute_frame", call it "minute_value" with Text property:

Text(_minute_value,"00")

And a new Image object under "minute_frame", call it "minute_down_icon" with this "Image" property:

And "OnSelect" property:

Set(_minute_value,Value(minute_value.Text)-1)

Step 6 - create am/fm content container

Add a new Vertical Container PCF object, call it "am_pm_frame" with this "Gap" property:

Add a new Image object under "am_fm_frame", call it "amfm_up_icon" with this "Image" property:

And "OnSelect" property:

If(_day_value = "AM",Set(_day_value,"PM"),Set(_day_value,"AM"))

And a new Label object under "am_fm_frame", call it "amfm_value" with Text property:

_day_value

And a new Image object under "am_fm_frame", call it "amfm_down_icon" with this "Image" property:

And "OnSelect" property:

If(_day_value = "PM",Set(_day_value,"AM"),Set(_day_value,"PM"))

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

12x Frame

6x Vector

4x Text

Procedure

Step 1 - create a time frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_time_picker" with these properties:

⁠

⁠

⁠

Step 2 - create a time content frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_time_frame" with these properties:

⁠

⁠

Step 3 - create an hour content frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_hour_frame" with these properties:

⁠

⁠

Import a new SVG file under a "vercont_hour_frame" frame, call it "svg_hour_up_icon" with this XML code:

Add a new Text (T command) object under a "vercont_hour_frame" frame, call it "lbl_hour_value" with these properties:

⁠

⁠

Import a new SVG file under a "vercont_hour_frame" frame, call it "svg_hour_down_icon" with this XML code:

Step 4 - create a separator content frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_sep_frame" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_sep_frame" frame, call it "lbl_separator" with these properties:

⁠

Step 5 - create a minute content frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_minute_frame" with these properties:

⁠

Import a new SVG file under a "vercont_minute_frame" frame, call it "svg_minute_up_icon" with this XML code:

Add a new Text (T command) object under a "vercont_minute_frame" frame, call it "lbl_minute_value" with these properties:

⁠

Import a new SVG file under a "vercont_minute_frame" frame, call it "svg_minute_down_icon" with this XML code:

Step 6 - create a am/fm content frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_am_pm_frame" with these properties:

⁠

Import a new SVG file under a "vercont_am_fm_frame" frame, call it "svg_amfm_up_icon" with this XML code:

Add a new Text (T command) object under a "vercont_am_fm_frame" frame, call it "lbl_amfm_value" with these properties:

⁠

Import a new SVG file under a "vercont_am_fm_frame" frame, call it "svg_amfm_down_icon" with this XML code:

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_time_picker, horcont_time_frame = Horizontal Container

vercont_hour_frame, vercont_sep_frame, vercont_minute_frame = Vertical Container

svg_hour_up_icon , svg_hour_down_icon = Image

lbl_hour_value , lbl_minute_value = Label

YAML Output

⁠

Used Colours

Time Background - #FFFFFF

Stroke Colour - #4F89FB

Icons Colour - #C9C9C9

Text Colour - #000000

⁠
