How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

6x Container

5x Label

1x Rectangle

1x Image

2x Circle

Procedure

Step 1 - create main container

Add a new Manual Container PCF, call it "status_report" with this "Gap" property:

and "DropShadow" property:

DropShadow.Regular

with CENTER vertical and STRETCH horizontal alignment.

Step 2 - create header container

Add a new Vertical Container PCF, call it "title_report_frame" with this "Gap" property:

And Label object under "title_report_frame", call it "title_report_value" with Text property:

"Delivered Project"

And Label object under "title_report_frame", call it "dscr_report_value" with Text property:

"Transited Knowledge"

Step 3 - create line container

Add a new Rectangle, call it "separator_line" with default properties.

Step 4 - create legend container

Add a new Horizontal Container PCF, call it "legend_report" with this "Gap" property:

with CENTER horizontal and STRETCH vertical alignment.

Add new Circle and Label under every Horizontal Container, call them "left/right_legend", "left/right_title_value" with these properties:

"Text" property:

"Active" , "Inactive"

"Color" property:

First Circle - RGBA(255, 153, 34, 1)

Second Circle - RGBA(217, 217, 217, 1)

Step 5 - create content container

Add a new Manual Container PCF, call it "content_report" with this "Height" property:

195

And Label object under "content_report", call it "report_value" with Text property:

"80%"

And Image object under "content_report", call it "report_img" with Image property:


This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

7x Frame

4x Text

1x Rectangle

2x Oval

10x Vector

Procedure

Step 1 - create a master frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_status_report" with these properties:

⁠

⁠

⁠

Step 2 - create a header frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_title_report_frame" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_title_report_frame" frame, call it "lbl_title_report_value" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_title_report_frame" frame, call it "lbl_dscr_report_value" with these properties:

⁠

⁠

Step 3 - create a line

Add a new Rectangle (R command) object, call it "rect_separator_line" with these properties:

⁠

⁠

Step 4 - create a legend frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_legend_report" with these properties:

⁠

⁠

Add new 2 Frames (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_left/right_legend_frame" with these properties:

⁠

⁠

Add 2 Oval (O command) objects for every horizontal frame, call it "ci_left/right_legend" with these properties:

⁠

⁠

⁠

Add 2 Text (T command) objects for every horizontal frame, call it "lbl_left/right_title_value" with these properties:

⁠

⁠

Step 3- create a content frame

Add a new Frame (F command) object, call it "cont_content_report" with these properties:

⁠

⁠

Add a Text (T command) object under "cont_content_report" frame, call it "lbl_report_value" with these properties:

⁠

⁠

Import a new SVG file under a "cont_content_report" frame, call it "svg_report_img" with this XML code:

</svg>

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_status_report, vercont_title_report_frame = Vertical Container

horcont_legend_report, horcont_left_legend_frame = Horizontal Container

cont_content_report = Manual Container

rect_separator_line = Rectangle

lbl_title_report_value, lbl_dscr_report_value, lbl_left_title_value, lbl_report_value = Label

svg_report_img = Image

ci_left_legend = Circle

YAML Output

⁠

Used Colours

Report Background - #F6F6F6

Title Font Colour - #000000

Dscr Font Colour - #D9D9D9

Active Chart Colour - #FF9922

Inactive Chart Colour - #D9D9D9

⁠
