How to design it in Power Apps

Preview

⁠
Screenshot 2024-09-15 at 9.37.04.png
⁠
⁠

What does it consist of?

1x Container
1x Text Input
1x Image

Procedure

Step 1 - create cover container
Add a new Horizontal Container PCF object, call it "searchbox" with this "DropShadow" property:
DropShadow.Semibold
Step 2 - create content
Add a new Text Input object, call it "input_search" with this "HintText" property:
"Search"
Add a new Image object, call it "search_icon" with this "Image" property:
This is an output:
⁠
Screenshot 2024-09-15 at 9.37.10.png
⁠
⁠

How to design it in Figma

Preview

⁠
Screenshot 2024-09-15 at 9.37.43.png
⁠
⁠

What does it consist of?

3x Frame
1x Text
1x Vector

Procedure

Step 1 - create horizontal frame
Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_searchbox" with these properties:
⁠
Screenshot 2024-09-15 at 9.49.12.png
⁠
⁠
Step 2 - create content for the parent frame
Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object under a "horcont_searchbox" frame, call it "txt_input_search" with these properties:
⁠
Screenshot 2024-09-15 at 9.50.46.png
⁠
⁠
Import a new SVG file under a "horcont_searchbox" frame, call it "svg_search_icon" with this XML code:
<svg width="50" height="50" viewBox="0 0 50 50" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M31.1533 31.1371L43.75 43.75M35.4167 20.8333C35.4167 28.8875 28.8875 35.4167 20.8333 35.4167C12.7792 35.4167 6.25 28.8875 6.25 20.8333C6.25 12.7792 12.7792 6.25 20.8333 6.25C28.8875 6.25 35.4167 12.7792 35.4167 20.8333Z" stroke="#53596C" stroke-width="5" stroke-linecap="round" stroke-linejoin="round"/>
</svg>
This is an output:
⁠
Screenshot 2024-09-15 at 9.38.31.png
⁠
⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_searchbox = Horizontal Container
txt_input_search = Text Input
svg_search_icon = Image

YAML Output

⁠
Screenshot 2024-09-15 at 9.46.55.png
⁠
⁠

Used Colours

Container Background - #FFFFFF
Hint Colour - #BEBFC3
Icon Colour - #53596C

⁠
