Pie Chart

Last edited 101 days ago by MyCondy
The component is a great helper to visualise stats like Profits, Costs, Summary, etc...

How to design it in Power Apps

Preview

Screenshot 2024-08-15 at 9.38.39.png

What does it consist of?

1x Group
2x Label
1x Image

Procedure

Step 1 - create a stat value with title
Add a new Label object, call it "automation_value" with this "text" property:
RoundUp((CountRows(Filter(<TABLE>,<TABLE COLUMN> = year_value.Text,<TABLE COLUMN> = "Automation"))/ CountRows(Filter(<TABLE>,<TABLE COLUMN> = year_value.Text)))*100,0)
Text inside "<>" character should be replaced by your real data.

Add a new Label object, call it "automation_label" with this "text" property:
"Automation[%]"
Step 2 - create a SVG image
Add a new Image object, call it "automation_image" with this "Image" property:
<circle r='90' cx='100' cy='100' fill='transparent' stroke='#e0e0e0' stroke-width='16px' stroke-dasharray='565px' stroke-dashoffset='0'></circle>
<circle r='90' cx='100' cy='100' stroke='#718AF4' stroke-width='16px' stroke-linecap='round' stroke-dashoffset='"&560 - (automation_value.Text *5)&"px' fill='transparent' stroke-dasharray='560px'></circle>
</svg>")
Step 3 - group all objects
Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).
This is an output:
Screenshot 2024-08-15 at 9.38.29.png

How to design it in Figma

Preview

Screenshot 2024-08-15 at 10.39.28.png

What does it consist of?

1x Group
1x Frame
2x Vector
2x Text

Procedure

Step 1 - create texts
Add a new Text (T command) object , call it "automation_title" with these properties:
Screenshot 2024-08-15 at 10.45.35.png
Add a new Text (T command) object , call it "automation_value" with these properties:
Screenshot 2024-08-15 at 10.46.06.png
Step 2 - create SVG donut
Import a new SVG file, call it "svg_automation_image" with this XML code:
<svg width="106" height="106" viewBox="0 0 106 106" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M53 100.7C79.344 100.7 100.7 79.344 100.7 53.0001C100.7 26.6561 79.344 5.30005 53 5.30005C26.656 5.30005 5.3 26.6561 5.3 53.0001C5.3 79.344 26.656 100.7 53 100.7Z" stroke="#E0E0E0" stroke-width="8.48"/>
<path d="M5.3 53C5.3 26.6561 26.656 5.30005 53 5.30005" stroke="#718AF4" stroke-width="8.48" stroke-miterlimit="1" stroke-linecap="round"/>
</svg>
This is an output:
Screenshot 2024-08-15 at 10.39.50.png

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

gr_pie_chart = Group
svg_dash_chart = Image
lbl_automation_value, lbl_automation_title = Label

YAML Output

Screenshot 2024-08-15 at 10.37.39.png

Used Colours

SVG Image Background - #E0E0E0
SVG Image Fill - #718AF4
Automation Title - #232323
Automation Value - #735667
