Popup Menu

MyCondy

Last edited 39 days ago by MyCondy

You will be able to show menu after clicking on icon placed on the base menu.

How to design it in Power Apps

Preview

⁠

⁠

⁠

What does it consist of?

1x Group

3x Vertical Container

1x Button PCF

3x Image

3x Label

1x HTML TEXT

Procedure

Step 1 - create Menu SVG image

Add a new Image object, call it "menu" with this "Image" property:


Step 2 - create menu item with selection

Add a new Image object, call it "folder" with this "Image" property:


and "Visible" property:

!selClick || IsBlank(selClick)

Add a new Image object, call it "folder_clicked" with this "Image" property:


and "Visible" property:

selClick

Add a new HTML TEXT object, call it "selection" with this "HTML text" property:

"<div style='border-radius:10px;background-color:#efefef;width:223px;height:4px;'></div>"

Add a new Button PCF object, call it "ButtonAdd" with this "Appearance" property:

'ButtonCanvas.Appearance'.Transparent

Step 3 - create popup menu items

Add a new Vertical Container PCF object, call it "word" with this "DropShadow" property:

DropShadow.Semibold

and "Border radius" property:

and "Visible" property:

selClick

Add a new Vertical Container PCF object, call it "excel" with this "DropShadow" property:

DropShadow.Semibold

and "Border radius" property:

and "Visible" property:

selClick

Add a new Vertical Container PCF object, call it "pdf" with this "DropShadow" property:

DropShadow.Semibold

and "Border radius" property:

and "Visible" property:

selClick

Step 4 - add labels for containers

Add a new Label object, call it "w" with this "Text" property:

Add a new Label object, call it "x" with this "Text" property:

Add a new Label object, call it "p" with this "Text" property:

Step 5 - group all objects

Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

1x Group

5x Frame

2x Rectangle

2x Vector

3x Text

Procedure

Step 1 - create menu box with selection

Add a new Rectangle (R command) object, call it "html_menu" with these properties:

⁠

⁠

⁠

Add a new Rectangle (R command) object, call it "html_selection" with these properties:

⁠

⁠

Step 2 - add menu icons

Import a new SVG file, call it "svg_folder" with this XML code:

Import a new SVG file, call it "svg_folder_clicked" with this XML code:

Step 3 - add popup items

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_word" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_word" frame, call it "lbl_w" with these properties:

⁠

⁠

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_excel" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_excel" frame, call it "lbl_x" with these properties:

⁠

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_pdf" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_pdf" frame, call it "lbl_p" with these properties:

⁠

Step 4 - group all objects

Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

gr_popup_menu = Group

vercont_pdf, vercont_excel, vercont_word = Vertical Container

lbl_p, lbl_x, lbl_x = Label

svg_folder, svg_folder_clicker = Image

html_selection, html_menu = HTML TEXT

YAML Output

⁠

Used Colours

Menu Image - #FFFFFF

Folder, Folder Clicked Image - #1D8CFF

Selection Image - #efefef

Word Container - #0171ff

Excel Container - #00bc48

PDF Container - #ff294a

⁠
