How to design it in Power Apps

Preview

⁠

⁠

⁠

What does it consist of?

4x Container

1x AddMedia

3x Image

1x Vertical Gallery

4x Label

1x Button

Procedure

Step 1 - create cover container

Add a new Vertical Container PCF object, call it "uploader" with this "Gap" property:

Step 2 - add header content for the main container

Add a new Image object, call it "empty_picture" with this "Image" property:


Add a new Label object, call it "picture_title" with this "text" property:

"Add a new picture file to upload"

Add a new Label object, call it "picture_dscr" with this "text" property:

"Your picture(s) will be private until publish them"

Step 3 - add media component under sub-container

Add a new Vertical Container PCF object, call it "media_frame" with this "Gap" property:

Add a new AddMedia object, call it "add_item" with this "OnChange" property:

ClearCollect(newRecord,{Title:First(Split(add_item.FileName,".")).Value,Suffix:Last(Split(add_item.FileName,".")).Value});

Patch(<Table>,Defaults(<Table>),{Title:First(newRecord).Title,<Table Column>:First(newRecord).Suffix,<Table Image Column>:savedImage.Image});

and "ChangePictureText" property:

"Add file item"

Replace <> by your real table with columns. AddMedia component will get if you put "Add Picture" and take only a button from created group in Power Apps. See example below:

⁠

⁠

Step 4 - add Gallery with data

Add a new Vertical Gallery object, call it "picture_gallery" with this "Data source" property:

<Table>

Replace <Table> by your SharePoint or Dataverse table.

Step 5 - add content for a gallery

Add a new Horizontal Container PCF object, call it "ïtem_frame" with this "DropShadow" property:

DropShadow.Semilight

Add a new Image object under item_frame, call it "picture_image" with this "Image" property:

First(ThisItem.Attachments).Value

Add a new Vertical Container PCF object under item_frame, call it "content_item" with this "Gap" property:

Add a new Label object under content_item, call it "picture_name" with this "text" property:

ThisItem.Title

Add a new Label object under content_item, call it "picture_type" with this "text" property:

ThisItem.<Table Column>

Replace <Table Column> by your real table column for image type.

Add a new Button object under item_frame, call it "remove_button" with this "Text" property:

"REMOVE"

and OnSelect property:

Remove(<Table>,ThisItem)

Replace <Table> by your SharePoint or Dataverse table.

Step 6 - add hidden image for uploaded picture (optional)

If you have some issue with PATCH function, that save a BLANK row in your table, you can use this step.

Add a new Image object, call it "savedImage" with this "Image" property:

add_item.Media

and Visible property:

false

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

8x Frame

10x Vector

6x Text

Procedure

Step 1 - create parent frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_uploader" with these properties:

⁠

⁠

Step 2- create content for a parent frame

Import a new SVG file under a "vercont_uploader" frame, call it "svg_empty_picture" with this XML code:

</svg>

Add a new Text (T command) object under a "vercont_uploader" frame, call it "lbl_picture_title" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_uploader" frame, call it "lbl_picture_dscr" with these properties:

⁠

⁠

Step 3 - add frame for media button

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_media_frame" with these properties:

⁠

⁠

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "addmedia_add_item" with these properties:

⁠

⁠

Add a new Text (T command) object under a "addmedia_add_item" frame, call it "Add File Item" with these properties:

⁠

⁠

Step 4 - add gallery frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object , call it "gall_pictures_gallery" with these properties:

⁠

⁠

Step 5 - add item under gallery frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object under a "gall_pictures_gallery" frame, call it "horcont_item_frame" with these properties:

⁠

⁠

⁠

Import a new SVG file under a "horcont_item_frame" frame, call it "img_picture_image" with this XML code:

</svg>

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object under a "horcont_item_frame" frame, call it "vercont_content_item" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_content_item" frame, call it "lbl_picture_name" with these properties:

⁠

⁠

Add a new Text (T command) object under a "vercont_content_item" frame, call it "lbl_picture_type" with these properties:

⁠

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object under a "horcont_item_frame" frame, call it "btn_remove_button" with these properties:

⁠

⁠

Add a new Text (T command) under a "btn_remove_button" frame, call it "REMOVE" with these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_uploader, vercont_media_frame, vercont_content_item = Vertical Container

horcont_item_frame = Horizontal Container

gal_picture_gallery = Vertical Gallery

svg_empty_picture, img_picture_image = Image

btn_remove_button = Button

addmedia_add_item = AddMedia

lbl_picture_title, lbl_picture_dscr, lbl_picture_name, lbl_picture_type = Label

YAML Output

⁠

Used Colours

Container Border Colour - #DFDFE1

Title Font Colour - #000000

Dscr Font Colour - #767980

Button Colour - #FE697F

Picture Item Background - #FFFFFF

⁠
