How to design it in Power Apps
Preview
What does it consist of?
Procedure
Step 1 - create vertical container
Add a new Vertical Container PCF object, call it "index_slider" with this "DropShadow" property:
DropShadow.Semilight
Step 2 - create content container
Add a new Manual Container PCF object, call it "slider_frame" with this "Height" property:
30
Add a new Circle object under "slider_frame", call it "slider_value" with X property:
151
This value you can replace by your data input from SharePoint or Dataverse.
Add a new Image object under "slider_frame", call it "index_icon" with Image property:
Step 3 - create label container
Add a new Horizontal Container PCF object, call it "labels_frame" with this "AlignInContainer" property:
AlignInContainer.Stretch
Add a new Label object under "labels_frame", call it "low_label" with Text property:
"Index - 0%"
Add a new Label object under "labels_frame", call it "max_label" with Text property:
"Index - 100%"
This is an output:
How to design it in Figma
Preview
What does it consist of?
Procedure
Step 1 - create a vertical frame with auto layout
Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_index_bar" with these properties:
Step 2 - create a content frame
Add a new Frame (F command) object, call it "cont_slider_frame" with these properties:
Add a new Oval (O command) under "cont_slider_frame", call it "ci_slider_value" with these properties:
Import a new SVG file, call it "svg_index_icon" with this XML code:
<svg width='325' height='17' viewBox='0 0 325 17' fill='none' xmlns='http://www.w3.org/2000/svg'> <path d='M0 8.5C0 3.80558 3.80558 0 8.5 0H65V17H8.5C3.80558 17 0 13.1944 0 8.5Z' fill='#D84949'/> <path d='M65 0H130V17H65V0Z' fill='#DC9233'/> <path d='M130 0H195V17H130V0Z' fill='#EAD453'/> <path d='M195 0H260V17H195V0Z' fill='#A2D742'/> <path d='M260 0H316.5C321.194 0 325 3.80558 325 8.5C325 13.1944 321.194 17 316.5 17H260V0Z' fill='#5CC488'/> </svg>
Step 3 - create labels frame
Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_labels_frame" with these properties:
Add a new Text (T command) object under a "horcont_labels_frame" frame, call it "lbl_low_title" with these properties:
Add a new Text (T command) object under a "horcont_labels_frame" frame, call it "lbl_max_title" with these properties:
This is an output:
