Custom Components

Icon with Notification

MyCondy

Last edited 104 days ago by MyCondy

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

1x Manual Container

1x Group

1x Image

1x HTML TEXT

1x Label

1x Circle

Procedure

Step 1 - create manual container

Add a new Container PCF object, call it "notification_frame".

Step 2 - create content for the container

Add a new HTML TEXT object, call it "notification_back" with this "HTML text" property:

"<div style='border-radius:10px;background:linear-gradient(#28d,#0be);width:100px;height:100px;'></div>"

Add a new Circle object, call it "notification_circle".

Add a new Label object, call it "notification_value" with Text property:

CountRows(<Table>)

Replace value between "<>" by your real table name.

Step 3 - group label and circle objects

Now, we select Label and Circle objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).

Step 4 - create icon image

Create an Image object, call it "notification" with Image property:


This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

2x Frame

1x Group

1x Vector

1x Oval

1x Text

1x Rectangle

Procedure

Step 1 - create a gradient rectangle

Add a new Rectangle (R command) object, call it "html_notification_back" with these properties:

⁠

⁠

Step 2 - create a notification icon

Import a new SVG file, call it "svg_notification" with this XML code:

</svg>

Step 2 - create a notification group value

Add a new Text (T command), call it "lbl_notification_value" with these properties:

⁠

⁠

Add a new Oval (O command), call it "ci_notification_circle" with these properties:

⁠

⁠

Select Text and Oval objects and press COMMAND + G (MAC) or CTRL + G (WIN) and call the group "gr_notification_group".

Step 3 - create a parent frame for all objects

Select Group,SVG, and Rectangle objects and press OPTION + COMMAND + G (MAC) or ALT + CONTROL + G (WIN) and call the frame: "cont_notification_frame".

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

cont_notification_frame = Manual Container

gr_notification_group = Group

svg_notification = Image

lbl_notification_value = Label

ci_notification_circle = Circle

html_notification_back = HTML Text

YAML Output

⁠

⁠

Used Colours

Rectangle Background - Gradient(#2580E0,#00C1F1)

Circle Background - #D65354

Text Colour - #FFFFFF

Icon Colour - #FFFFFF

⁠
