Custom Components

icon picker
Feedback Box

MyCondy
Last edited 54 days ago by MyCondy

How to design it in Power Apps

Preview

⁠
Screenshot 2024-10-19 at 6.57.58.png
⁠
⁠

What does it consist of?

7x Container
2x Label
5x Button
5x Image

Procedure

Step 1 - create feedback box
Add a new Vertical Container PCF object, call it "feeling_box" with this "DropShadow" property:
DropShadow.Semibold
with CENTER horizontal and CENTER vertical alignment.
Step 2 - create title texts
Add a new Label object, call it "feeling_title" with Text property:
"How are you feeling?"
And a new Label object, call it "dscr_feeling_title" with Text property:
"Your input can help us to better understand"
Step 3 - create content frame
Add a new Horizontal Container PCF object, call it "feeling_box" with this "Gap" property:
10
with CENTER horizontal and CENTER vertical alignment.
Step 4 - create emoji frames
Add 5 Vertical Container PCF objects, call it "sad/not_bad/neutral/good/love_frame" with this "Gap" properties:
10
with CENTER horizontal and STRETCH vertical alignment.

And create 5 Image objects, call it "sad/not_bad/neutral/good/love_icon" with Image properties:
Sad
Not Bad
Neutral
Good
Love
This is an output:
⁠
Screenshot 2024-10-19 at 6.57.51.png
⁠
⁠

How to design it in Figma

Preview

⁠
Screenshot 2024-10-19 at 7.14.14.png
⁠
⁠

What does it consist of?

12x Frame
7x Text
5x Vector

Procedure

Step 1 - create a feeling frame with auto layout
Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_feeling_box" with these properties:
⁠
Screenshot 2024-10-19 at 7.37.49.png
⁠
⁠
⁠
Screenshot 2024-10-19 at 7.38.05.png
⁠
⁠
Step 2 - create texts
Add a new Text (T command) object, call it "lbl_feeling_title" with these properties:
⁠
Screenshot 2024-10-19 at 7.39.31.png
⁠
⁠
Add a new Text (T command) object, call it "lbl_dscr_feeling_title" with these properties:
⁠
Screenshot 2024-10-19 at 7.40.01.png
⁠
⁠
Step 3 - create content frame
Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_feeling_content" with these properties:
⁠
Screenshot 2024-10-19 at 7.41.19.png
⁠
⁠
Step 4 - create emoji frames
Add 5 new Frames (F command) with vertical auto layout (SHIFT + A command) object, call them "vercont_sad/not_bad/neutral/good/love_frame" with these properties:
⁠
Screenshot 2024-10-19 at 7.44.50.png
⁠
⁠
Import 5 new SVG files, call them "svg_sad/not_bad/neutral/good/love_icon" with XML code(the same SVG codes as in previous section)
Add 5 new Frames (F command) with horizontal auto layout (SHIFT + A command) object, call them "btn_sad/not_bad/neutral/good/love_button" with these properties:
⁠
Screenshot 2024-10-19 at 7.49.15.png
⁠
⁠
the same properties, but different colour.
Add 5 new Text (T command) object, call it "Sad/Not Bad/Neutral/Good/Love" with these properties:
⁠
Screenshot 2024-10-19 at 7.51.26.png
⁠
⁠
the same properties for the rest, but different text value.
This is an output:
⁠
Screenshot 2024-10-19 at 7.14.46.png
⁠
⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_feeling_box, vercont_sad_frame = Vertical Container
horcont_feeling_content = Horizontal Container
btn_sad_button = Button
lbl_feeling_title, lbl_dscr_feeling_title = Label
svg_sad_icon = Image

YAML Output

⁠
⁠
⁠

Used Colours

Feeling Background - #FFFFFF
Title Font Colour - #3E4EA6
Dscr Font Colour - #808080
Sad Button Background - #3E4EA6
Not Bad Button Background - #3BC5F6
Neutral Button Background - #FFB32B
Good Button Background - #0FA298
Love Button Background - #CF4054

⁠
