Custom Components

Counter

MyCondy

Last edited 21 days ago by MyCondy

The component helps you to increase and decrease your value.

How to design it in Power Apps

Preview

⁠

⁠

⁠

What does it consist of?

1x Horizontal Container

2x Image

1x Label

Procedure

Step 1 - create counter container

Add a new Horizontal Container PCF object, call it "counter" with this "DropShadow" property:

DropShadow.Semibold

Step 2 - add content for the container

Add a new Image object, call it "rem_count" with this "Image" property:


and "OnSelect" property:

If(count_val = 1,Set(count_val,1), Set(count_val,count_val-1))

And a new Label object, call it "value_count" with Text property:

If(IsBlank(count_val),1, count_val)

Add a new Image object, call it "add_count" with this "Image" property:


and "OnSelect" property:

If(count_val < 99,Set(count_val,count_val+1))

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

3x Frame

1x Text

2x Vector

Procedure

Step 1 - create a horizontal frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_counter" with these properties:

⁠

⁠

⁠

Step 2 - create a content for the parent frame

Import a new SVG file under a "horcont_counter" frame, call it "svg_rem_count" with this XML code:

</svg>

Add a new Text (T command) object under a "horcont_counter" frame, call it "lbl_value_count" with these properties:

⁠

⁠

Import a new SVG file under a "horcont_counter" frame, call it "svg_add_count" with this XML code:

</svg>

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_counter = Horizontal Container

svg_rem_count, svg_add_count = Image

lbl_value_count = Label

YAML Output

⁠

⁠

Used Colours

Frame Stroke - #DBDBDB

Frame Background - #FFFFFF

Label Colour - #232323

Remove Counter Colour - #DBDBDB

Add Counter Colour - #316BB7

⁠
