Colour Picker

MyCondy

Last edited 21 days ago by MyCondy

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

2x Container

1x Rectangle

1x Image

9x Circle

Procedure

Step 1 - create boolean variable on Screen

When you create a new screen(or use already created) you should create a variable on "OnVisible" property:

Set(collapsed,true);Set(default_colour,RGBA(35, 37, 41, 1))

Step 2 - create picker box

Add a new Horizontal Container PCF object, call it "text_exp_colour_picker" with this "DropShadow" property:

DropShadow.Light

with CENTER vertical and START horizontal alignment.

Step 3 - create selected circle with divider

Add a new Circle object, call it "selected_colour_exp" with this "Fill" property:

default_colour

Add a new Image object, call it "expand_icon_exp" with this "Image" property:


Add a new Rectangle object, call it "divider_exp" with this "Fill" property:

RGBA(217, 217, 217, 1)

Step 4 - create colours

Add a new Horizontal Container PCF object, call it "colours_frame_exp" with this "OnVisible" property:

If(collapsed || IsBlank(collapsed),false,true)

Add 8 Circle objects, call them "col1/2/3/4/5/6/7/8_exp" with this "Height/Width" properties:

and use Fill according to mentioned colours in USED COLOURS section below.

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

3x Frame

1x Vector

9x Ellipse

1x Rectangle

Procedure

Step 1 - create a picker frame with auto layout

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "horcont_text_col_colour_picker" with these properties:

⁠

⁠

Step 2 - create a selected colour with divider

Add a new Ellipse (O command) object, call it "ci_selected_colour_col" with these properties:

⁠

⁠

Import a new SVG file call it "svg_collapse_icon_col" with this XML code:

Add a new Rectangle (R command) object, call it "rect_divider_col" with these properties:

⁠

⁠

Step 3 - create colour values in frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "horcont_colours_frame_col" with these properties:

⁠

⁠

Add 8 new Ellipse (O command) objects, call them "ci_col1/2/3/4/5/6/7/8_col" with these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_text_col_colour_picker = Horizontal Container

ci_selected_colour_col = Circle

svg_collapse_icon_col = Image

rect_divider_col = Rectangle

YAML Output

⁠

Used Colours

Background - #FFFFFF

Selected Circle Colour, Colour 1 - #232529

Colour 2 - #5C6169

Colour 3 - #FF5A59

Colour 4 - #E8657E

Colour 5 - #EC973B

Colour 6 - #41C262

Colour 7 - #627BE3

Colour 8 - #8C61E5

⁠
