Final Presentation

⁠
WhatsApp Image 2023-02-21 at 1.54.21 PM.jpeg
⁠
⁠
Final Presentation Program
Date
Time
Activity
Venue
Notes
2/20/2023
1
​4:00 PM
Briefing on Final Presentation Preparation of the Venue Dry Run
Block B
Open
2/21/2023
6
​8:30 AM
Arrival of the guest panels
Block B
Open
​9:00 AM
Briefing on the project + Breakfast
FABE Gallery
Open
​9:30 AM
Final Presentation Start
Various Venue
Open
​12:30 PM
Final Presentation End Wrap up Session
Various Venue
Open
​1:00 PM
Lunch
FABE Gallery
Open
​2:00 PM
End of Event
​
Open
⁠

Guide Information:


Project Title

Putrajaya Halfway House

“a temporary accommodation facility for relatives of patients receiving treatment at the (nearby) hospitals.”
Further detail information about the project:

⁠
Design Brief
⁠
⁠

⁠
Scenario & Tasks
⁠
⁠

⁠
Schedule of Accommodation
⁠
⁠

⁠
Course Syllabus
⁠
⁠

Note:

Please take note that Design Studio 3B has been experimenting in a BIM and Digital Presentation Initiative.
The objective of this initiative is to prepare students for the practice of producing digital presentations against the current practice that using printing on paper.
We are trying to reduce the use of printed presentation drawings as the main presentation medium.
It was believed that by having digital presentations the student can reduce the cost and time of architectural production.
The initiative is run sync with the BIM introduction as part of the studio program.

Presentation Items and Medium

Students are required to produce:
Printed Drawings (B&W A1 size) that consist of at least:
Site Plan with roof plan (min 1: 500)
Ground Floor Plan with context (GFPx) of the surrounding (min 1: 250)
Ground Floor Plan (GFP) with less context (min 1: 200)
Basement Floor Plan (the same scale as GFP)
Each Upper Floor Plans (the same scale as GFP)
4 Elevations (the same scale as GFP)
2 Sections (the same scale as GFP)
1 Typical Sections of External wall (min 1:50)
Digital Presentation Drawings that consist of at least:
Design Concept and Precedents
Sustainability Approach and Strategy
Building System Design (LOD 100)
Massing Concept
Circulation Concept
Services Concept
SOA
All the printed drawings as mentioned above in colour
Floor Plans (LOD 250)
Sections (LOD 250)
Elevations (LOD 250)
Callout Plans
Callout Floor Plan for Each Room Type (LOD 300)
Callout 3D of Each Room Type (LOD 300)
Typical Sections of Facade (LOD350)
3D Drawings
Overall Axonometric of the building
Exploded Axonometric
Exterior Perspectives
Interior Perspectives
3D Section Detail Model (physical)
A physical model that shows the concept of structural configuration in the building
Stretched KPI - Digital Presentation
Sectional Perpectives
Walkthrough Animations
Presentation/Interactive Virtual Tour
Building Performance Analysis
Shadow Analysis
Building Energy Intensity Projection
Space Lighting Analysis: Daylight Factor and Illuminace

The Final Presentation Panels
⁠
Final Presentation Group
⁠

Scoring Rubrics

⁠
⁠
⁠
