Tooltip

Lukas Pavelka

Last edited 213 days ago by Lukas Pavelka.

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

3x Container

2x Image

1x Icon

3x Label

1x Rectangle

Procedure

Step 1 - create boolean variable on Screen

When you create a new screen(or use already created) you should create a variable on "OnVisible" property:

Set(_tooltip,false)

Step 2 - create fake clickable background

Add a new Rectangle object, call it "back_screen" with this "Fill" property:

RGBA(0, 0, 0, 0)

and "OnSelect" property:

Set(_tooltip,false)

Step 3 - create title with clickable icon

Add a new Label object, call it "title" with Text property:

"Activity Growth:"

And add Image object, call it "icon_info" with Image property:


Step 3 - create a main tooltip container

Add a new Vertical Container PCF object, call it "tooltip_frame" with this "DropShadow" property:

DropShadow.Semibold

with padding property - top: 10, bottom:0, left: 10, right: 10

and Visible property:

_tooltip

Step 4 - create top container

Add a new Horizontal Container PCF object, call it "header_tooltip_frame" with this "Gap" property:

Add a new Image object under header_tooltip_frame, call it "chart_tooltip_icon" with this "Image" property:


Add a new Label object under header_tooltip_frame, call it "title_tooltip" with Text property:

"Ativity growth - Incremental"

Add a new Icon object under header_tooltip_frame, call it "close_tooltip_icon" with this "OnSelect" property:

Set(_tooltip,false)

and Icon property:

Icon.CancelBadge

Step 5 - create bottom container

Add a new Horizontal Container PCF object, call it "dscr_tooltip_frame" with this "Gap" property:

Add a new Label object under dscr_tooltip_frame, call it "dscr_tooltip" with Text property:

"Report helps navigate cumulative (all-

time) growth of community activities. Ideally, the chart should have a growing trend, as stagnating chart signifies a significant decrease of

community activity."

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

5x Frame

3x Vector

2x Text

Procedure

Step 1 - create a tooltip frame with auto layout

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_tooltip_frame" with these properties:

⁠

⁠

⁠

Step 2 - create a header frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_header_tooltip_frame" with these properties:

⁠

⁠

Import a new SVG file, call it "svg_chart_tooltip_icon" with XML code

Add a new Text (T command) object, call it "lbl_title_tooltip" with these properties:

⁠

⁠

Import a new SVG file, call it "svg_close_tooltip_icon" with XML code

Step 3 - create a content frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_dscr_tooltip_frame" with these properties:

⁠

⁠

Add a new Text (T command) object, call it "lbl_dscr_tooltip" with these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_tooltip_frame = Vertical Container

horcont_header_tooltip_frame, horcont_dscr_tooltip_frame = Horizontal Container

svg_chart_tooltip_icon, svg_close_tooltip_icon = Image

lbl_title_tooltip, lbl_dscr_tooltip = Label

NEW YAML Output

⁠

Used Colours

Background - #FFFFFF

Font Colour - #000000

Icon Colour - #604EB2

⁠
