How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

1x Vertical Gallery

2x Container

1x Checkbox PCF

1x Image

Procedure

Step 1 - create gallery

Add a new Vertical Gallery object, call it "todos_gallery" with this "Items" property:

[

{Title: "Onboard Customer",Type: "HR",Colour: "#D4DEFF",TextColour: "#36399E"},

{Title: "Send Report to Boss",Type: "Project",Colour: "#E4D4FF",TextColour: "#5D32E9"},

{Title: "Order new HW",Type: "Buyer",Colour: "#F5D7E0",TextColour: "#7F333C"}

]

You can use SharePoint list or DataVerse table instead of static items.

Step 2 - create item in gallery

Add a new Horizontal Container object, call it "todo_frame" with this "Gap" property:

Add a new CheckBox PCF object, call it "check_item" with this "Text" property:

ThisItem.Title

Add a new Horizontal Container object, call it "type_frame" with this "Height" property:

and "Color" property:

ColorValue(ThisItem.Colour)

Add a new Label object under "type_frame", call it "type_value" with this "Text" property:

ThisItem.Type

and "Color" property:

ColorValue(ThisItem.TextColour)

Add a new Image object, call it "action_icon" with this "Text" property:


This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

4x Frame

1x CheckBox Component

1x Text

1x Vector

Procedure

Step 1 - create horizontal gallery frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "gall_todos_gallery" with these properties:

⁠

⁠

Step 2 - create item frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_todo_frame" with these properties:

⁠

⁠

Step 3 - import CheckBox component

Open DesignKit PRO 2.5 version and import CheckBox PCF component:

⁠

⁠

Step 4 - create type frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_type_frame" with these properties:

⁠

⁠

Add a new Text (T command) object under a "horcont_type_frame" frame, call it "lbl_type_value" with these properties:

⁠

⁠

Import a new SVG file under a "horcont_type_frame" frame, call it "svg_action_icon" with this XML code:

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

gall_todos_gallery = Vertical Gallery

horcont_todo_frame = Horizontal Container

checkpcf_check_item = CheckBox PCF

lbl_type_value = Label

svg_action_icon = Image

YAML Output

⁠

Used Colours

Item Background - #FFFFFF

Item Stroke Colour - #C1B1A1

Type Colours - #D4DEFF , #E4D4FF , #F5D7E0

Text Colours - #36399E , #5D32E9 , #7F333C

⁠
