How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

2x Container

1x Text Input PCF

11x Image

Procedure

Step 1 - create boolean variables on Screen

Set(left_prop,false);Set(center_prop,false);Set(right_prop,false);Set(bold_prop,false);Set(italic_prop,false);Set(underline_prop,false);Set(h1_prop,false);Set(h2_prop,false);Set(h3_prop,false)

Step 2 - create richtext container

Add a new Vertical Container PCF object, call it "richtext_custom" with this "DropShadow" property:

DropShadow.Semibold

Step 3 - create text input

Add a new Text Input object under "richtext_custom", call it "multiline" with this "HintText" property:

"insert text..."

and "Mode" property:

'TextInputCanvas.Mode'.Multiline

and "Align" property:

If(left_prop,'TextInputCanvas.Align'.Start,center_prop, 'TextInputCanvas.Align'.Center,right_prop,'TextInputCanvas.Align'.End)

and "FontWeight" property:

If(bold_prop,FontWeight.Bold,italic_prop,FontWeight.Lighter, FontWeight.Normal)

and "FontItalic" property:

italic_prop

and "FontUnderline" property:

underline_prop

and "FontSize" property:

If(h1_prop, 40,h2_prop,30,h3_prop,20)

Step 4 - create action icons

Add a new Horizontal Container PCF object, call it "icons_frame" with this "Gap" property:

And add these Images objects with "Image" properties:

Left Icon


Center Icon


Right Icon


Divider Icon


Bold Icon


Italic Icon


Underline Icon


Header 1 Icon


Header 2 Icon


Header 3 Icon


And "OnSelect" property (Aligns properties):

If(left_prop,'TextInputCanvas.Align'.Start,center_prop, 'TextInputCanvas.Align'.Center,right_prop,'TextInputCanvas.Align'.End)

You can do this for the rest icons, like bold, italic, underline, or headers.

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

14x Frame

14x Vector

1x Text

Procedure

Step 1 - create vertical frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_richtext_custom" with these properties:

⁠

⁠

Step 2 - create text input

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object under a "vercont_richtext_custom" frame, call it "txtpcf_multiline" with these properties:

⁠

⁠

Add a new Text (T command) object under a "txtpcf_multiline" frame, call it "insert text..." with these properties:

⁠

⁠

Step 3 - create action icons

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object under a "vercont_richtext_custom" frame, call it "horcont_icons_frame" with these properties:

⁠

⁠

Add Vectors under this frame, you can use SVG code from the previous section.

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_richtext_custom = Vertical Container

txtpcf_multiline = Text Input

horcont_icons_frame = Horizontal Container

svg_align_left_icon = Image

YAML Output

⁠

Used Colours

Richtext Background - #FFFFFF

Icons Frame Background - #F5F5F5

Text Colour - #000000

Icons Colour - #212121

⁠
