Canvas Components

Link Input Field

Lukas Pavelka

Last edited 152 days ago by Lukas Pavelka.

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

1x Container

1x Image

1x Label

1x Rectangle

Procedure

Step 1 - create link container

Add a new Horizontal Container PCF object, call it "link_frame" with this "Gap" property:

Step 2 - create content of the container

Add a new Image object under "link_frame", call it "link_icon" with Image property:


and add a new Label object object under "link_frame", call it "prefix_link" with Text property:

"https://"

and add a new Rectangle object under "link_frame", call it "divider_link" with this "Color" property:

RGBA(139, 139, 139, 1)

and add a new Text Input PCF object under "link_frame", call it "value_link" with this "HintText" property:

"insert text..."

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

3x Frame

1x Rectangle

1x Vector

2x Text

Procedure

Step 1 - create a horizontal frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_link_frame" with these properties:

⁠

⁠

Step 2 - create a content for the parent frame

Import a new SVG file under a "horcont_link_frame" frame, call it "svg_link_icon" with this XML code:

Add a new Text (T command) object under a "horcont_link_frame" frame, call it "lbl_prefix_link" with these properties:

⁠

⁠

Add a new Rectangle (R command) object under "horcont_link_frame", call it "rect_divider_link" with these properties:

⁠

⁠

Step 3 - import CheckBox component

Open DesignKit PRO 3.0 version and import Text PCF component:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_link_frame = Horizontal Container

svg_link_icon = Image

lbl_prefix_link = Label

rect_divider_link = Rectangle

txtpcf_value_link = Modern Text PCF

YAML Output

⁠

Used Colours

Background Colour - #FFFFFF

Stroke Colour - #C9B4E6

Font Colour - #1D1D1D

Prefix Colour - #8B8B8B

⁠
