Light/Dark Mode

MyCondy

Last edited 87 days ago by MyCondy

Modern toggle for switching theme colours by selected mode.

How to design it in Power Apps

Preview

⁠

⁠

⁠

What does it consist of?

3x Horizontal Container

2x Label

2x Image

Procedure

Step 1 - create boolean variable on Screen

When you create a new screen(or use already created) you should create a variable on "OnVisible" property:

Set(_var_light_mode,true)

Step 2 - create light mode container

Add a new Horizontal Container PCF, call it "light_mode_frame" with this "Border radius" property:

Step 3 - create modes for parent container

Add a new Horizontal Container PCF, call it "light_mode" with this "Border radius" property:

And Label object under "light_mode", call it "light_mode_title" with Text property:

Light

And Image object under "light_mode", call it "light_mode_icon" with Image property:


Add a new Horizontal Container PCF, call it "dark_light_mode" with this "Border radius" property:

And Image object under "dark_light_mode", call it "dark_light_mode_icon" with Image property:


and "OnSelect" property:

Set(_var_light_mode,false)

And Label object under "dark_light_mode", call it "dark_light_mode_title" with Text property:

Dark

and "OnSelect" property:

Set(_var_light_mode,false)

Step 4 - create dark mode container

Add a new Horizontal Container PCF, call it "dark_mode_frame" with this "Border radius" property:

Step 5 - create modes for parent container

Add a new Horizontal Container PCF, call it "light_dark_mode" with this "Border radius" property:

And Label object under "light_dark_mode", call it "light_mode_title" with Text property:

Light

and "OnSelect" property:

Set(_var_light_mode,true)

And Image object under "light_dark_mode", call it "light_mode_icon" with Image property:


and "OnSelect" property:

Set(_var_light_mode,true)

Add a new Horizontal Container PCF, call it "dark_mode" with this "Border radius" property:

And Label object under "dark_mode", call it "dark_title" with Text property:

Dark

And Image object under "dark_mode", call it "dark_icon" with Image property:


Step 6 - add dynamic colour for screen background

Go to "Fill" property in your screen(s) and put this value:

If(IsBlank(_var_light_mode) || _var_light_mode,RGBA(244,244,244,1), RGBA(17, 19, 21, 1))

This is an output:

Light

⁠

⁠

Dark

⁠

⁠

How to design it in Figma

Preview

⁠

What does it consist of?

5x Frame

2x Text

3x Vector

Procedure

Step 1 - create a horizontal frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_light_mode_frame" with these properties:

⁠

⁠

Step 2 - create light and dark horizontal frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_light_mode" with these properties:

⁠

⁠

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_dark_light_mode" with these properties:

⁠

⁠

Step 3 - insert icons and texts under parent frames

Import a new SVG file under a "horcont_light_mode" frame, call it "svg_light_mode_icon" with this XML code:

</svg>

Add a new Text (T command) object under a "horcont_light_mode" frame, call it "lbl_light_mode_title" with these properties:

⁠

⁠

Import a new SVG file under a "horcont_dark_light_mode" frame, call it "svg_dark_light_mode_icon" with this XML code:

</svg>

Add a new Text (T command) object under a "horcont_dark_light_mode" frame, call it "lbl_dark_light_mode_title" with these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_light_mode_frame, horcont_light_mode, horcont_dark_light_mode = Horizontal Container

svg_light_mode_icon , svg_dark_light_mode_icon = Image

lbl_light_mode_title, lbl_dark_light_mode_title = Label

YAML Output

LightMode

⁠

Dark Mode

⁠

Used Colours

Parent Light Container Background - #F4F4F4

Light Frame Background - #FFFFFF

Light Font Colour - #000000

Parent Dark Container Background - #111315

Dark Frame Background - #272B2F

Dark Font Colour - #FFFFFF

⁠
