Custom Components

Info Popup with Button

MyCondy

Last edited 28 days ago by MyCondy

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

4x Container

1x Rectangle

1x Image

1x Button

2x Label

Procedure

Step 1 - create popup container with divider

Add a new Horizontal Container PCF object, call it "info_popup" with this "DropShadow" property:

DropShadow.Semibold

Add a new Rectangle object under "info_popup", call it "info_divider" with this "Color" property:

RGBA(79, 167, 247, 1)

Step 2 - create content container

Add a new Vertical Container PCF object, call it "content_frame" with this "Gap" property:

Step 3 - create top container

Add a new Horizontal Container PCF object, call it "top_frame" with this "Gap" property:

Add a new Image object under "light_mode", call it "info_icon" with Image property:


and add a new Label object, call it "message_value" with Text property:

"A new software is available. See what's new in the last version."

and add a new Label object, call it "close_button" with Text property:

"X"

Step 4 - create bottom container

Add a new Horizontal Container PCF object, call it "bottom_frame" with this "Gap" property:

Add a new Button object, call it "info_button" with this "Text" property:

"View the changelog"

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

6x Frame

1x Rectangle

1x Vector

2x Text

Procedure (for blue info popup)

Step 1 - create a horizontal frame with auto layout and divider

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_info_popup" with these properties:

⁠

⁠

Add a new Rectangle (R command) object under a "horcont_info_popup" frame, call it "rect_info_divider" with these properties:

⁠

⁠

Step 2 - create a content frame

Add a new Frame (F command) with vertical auto layout (SHIFT + A command) object, call it "vercont_content_frame" with these properties:

⁠

⁠

Step 3 - create a top frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_top_frame" with these properties:

⁠

⁠

Import a new SVG file, call it "svg_info_icon" with this XML code:

Add a new Text (T command) object under a "horcont_top_frame" frame, call it "lbl_message_value" with these properties:

⁠

⁠

Add a new Text (T command) object under a "horcont_top_frame" frame, call it "lbl_close_button" with these properties:

⁠

⁠

Step 4 - create a bottom frame

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_bottom_frame" with these properties:

⁠

⁠

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "btn_info_button" with these properties:

⁠

⁠

Into the frame you need to create a Text (T command) node with "View the changelog" text and these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_info_popup, horcont_top_frame, horcont_bottom_frame = Horizontal Container

vercont_content_frame = Vertical Container

btn_info_button = Button

lbl_message_value, lbl_close_button = Label

svg_info_button = Image

YAML Output

⁠

Used Colours

Background Popup - #F2FAFC

Text Colour - #275886

Icon Colour - #4FA7F7

Button Background - #FFFFFF

Button Stroke Colour - #D9DBDE

⁠
