The accordion can minimise or maximise your data inside the box.
How to design it in Power Apps
Preview
What does it consist of?
Procedure
Step 1 - create boolean variable on Screen
When you create a new screen(or use already created) you should create a variable on "OnVisible" property:
Set(_var_minmax,false)
Step 2 - create HTML accordion box
Add a new HTML TEXT object, call it "accordion_box" with this "HTML text" property:
"<div style='margin:0px;width:"&Self.Width-5&"px;height:"&Self.Height-5&"px;background-color:#fff; border-radius:10px; border: 4px; border-style: solid; border-color:#2D92FA;'></div>"
and "Height" property:
If(_var_minmax,342/3-22, 342)
It is up to you of how height your box will be.
Step 3 - create header HTML box
Add a new HTML TEXT object, call it "header_box" with this "HTML text" property:
"<div style='margin:0px;width:"&Self.Width-5&"px;height:85px;background-color:#2D92FA; border-radius:10px; border: 2px; border-style: solid; border-color:#2D92FA;'></div>"
Again, the height of this html div could be different. It is your choice.
Step 4 - create title for the accordion
Add a new TEXT PCF object, call it "accordion_title" with this "Text" property:
"Report"
Step 5 - add SVG icons
Add a new Image object, call it "min_icon" with this "Image" property:
<path d='M994.034 694.296c-18.796-27.296-49.269-27.3-68.067 0l-351.074 509.836c-18.797 27.296-7.18 49.424 25.959 49.424h718.297c33.133 0 44.757-22.125 25.959-49.424L994.034 694.296Z' fill-rule='evenodd'/>
</svg>")
and "Visible" property:
If(IsBlank(_var_minmax) || _var_minmax,true,false)
Add a new Image object, call it "max_icon" with this "Image" property:
<path d='M994.034 1226.26c-18.796 27.296-49.269 27.3-68.067 0L574.893 716.424C556.096 689.128 567.713 667 600.852 667h718.297c33.133 0 44.757 22.125 25.959 49.424L994.034 1226.26Z' fill-rule='evenodd'/>
</svg>")
and "Visible" property:
If(IsBlank(_var_minmax) || _var_minmax,false,true)
Step 6 - group all objects
Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).
This is an output:
How to design it in Figma
Preview
What does it consist of?
Procedure
Step 1 - create accordion frame
Add a new Frame (F command) object, call it "cont_accordion_frame" with these properties:
Step 2 - create content for the frame
Add a new Rectangle (R command) object under a "cont_accordion_frame" frame, call it "html_header_box" with these properties:
Import a new SVG file, call it "svg_down_icon" with this XML code:
<svg width="13" height="15" viewBox="0 0 13 15" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M11.2352 2H1.3472L6.29118 13L11.2352 2Z" fill="white" stroke="white" stroke-width="2.35714" stroke-linecap="round" stroke-linejoin="round"/>
</svg>
Import a new SVG file, call it "svg_up_icon" with this XML code:
<svg width="13" height="15" viewBox="0 0 13 15" fill="none" xmlns="http://www.w3.org/2000/svg">
<path d="M11.2351 13H1.34717L6.29115 2L11.2351 13Z" fill="white" stroke="white" stroke-width="2.35714" stroke-linecap="round" stroke-linejoin="round"/>
</svg>
Add a new Text (T command) object under a "horcont_content_info" frame, call it "lbl_accordion_title" with these properties:
Step 3 - group all objects
Now, we select all objects and group them via shortcut - COMMAND + G (MAC) , CONTROL + G (WIN).
This is an output:
How to use it via DesignKit
Prerequisites
Used Prefixes
YAML Output
Used Colours
