Custom Components

Breadcrumb

MyCondy

Last edited 11 minutes ago by MyCondy

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

2x Container

3x Image

2x Label

Procedure

Step 1 - create main container

Add a new Horizontal Container PCF, call it "breadcrumb_frame" with this "Gap" property:

Step 2 - create home icon container

Add a new Horizontal Container PCF, call it "icon_frame" with this "Gap" property:

Add a new Image object, call it "home_icon" with this "Image" property:


Step 3 - create first level icon

Add a new Image object, call it "first_level_icon" with this "Image" property:


Step 4 - create screen name value

Add a new Label object, call it "screen_name" with Text property:

<Your_screen_name>.Name

Step 5 - create second level icon

Add a new Image object, call it "second_level_icon" with this "Image" property:

Step 6 - create screen title value

Add a new Label object, call it "screen_value" with Text property:

"DesignKit"

you can use dynamic value, like selected gallery item, or record in your table.

This is an output:

⁠

⁠

How to design it in Figma

Preview

⁠

⁠

What does it consist of?

5x Frame

2x Text

3x Vector

Procedure

Step 1 - create a parent frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_breadcrumb_frame" with these properties:

⁠

⁠

Step 2 - create a icon frame with auto layout

Add a new Frame (F command) with horizontal auto layout (SHIFT + A command) object, call it "horcont_icon_frame" with these properties:

⁠

⁠

Import a new SVG file under a "horcont_icon_frame" frame, call it "svg_home_icon" with this XML code:

Step 3 - create a first level icon

Import a new SVG file, call it "svg_first_level_icon" with this XML code:

Step 4 - create a first level text

Add a new Text (T command) object, call it "lbl_screen_name" with these properties:

⁠

⁠

Step 5 - create a second level icon

Import a new SVG file, call it "svg_first_level_icon" with this XML code:

Step 6 - create a second level text

Add a new Text (T command) object, call it "lbl_screen_value" with these properties:

⁠

⁠

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_breadcrumb_frame, horcont_icon_frame = Horizontal Container

svg_home_icon, svg_first_level_icon, svg_second_level_icon = Image

lbl_screen_name, lbl_screen_value = Label

YAML Output

⁠

Used Colours

Home Icon Background - #E6E6E6

Home Icon Colour - #3F4D61

Active Text Colour - #3F4D61

Inactive Text Colour - #A3A9B4
