Explore

Verification Code

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

3x Container

1x Image

4x Modern Text Input

2x Modern Button

2x Label

Procedure

Step 1 - create main container

Add a new Vertical Container PCF, call it "verify_frame" with this "Gap" property:

Step 2 - create content

Add a new Image object, call it "verify_icon" with this "Image" property:


And Label object under "verify_frame", call it "verify_title" with Text property:

"Enter Verification Code"

And Label object under "verify_frame", call it "verify_dscr" with Text property:

"Enter the 4-digit code we sent to email. Didn't receive a code? Try again."

Step 3 - create codes container

Add a new Horizontal Container PCF, call it "verify_codes_frame" with this "Gap" property:

Add 4 new Text Input PCFs, call it "number_1/2/3/4" with this "BorderColor" property:

RGBA(96, 135, 204, 1)

Step 4 - create buttons container

Add a new Horizontal Container PCF, call it "verify_buttons" with this "Gap" property:

Add 2 new Button PCFs, call it "cancel/confirm_button" with this "Font" property:

"Clash Display"

This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

vercont_verify_frame = Vertical Container

horcont_verify_codes_frame, horcont_verify_buttons = Horizontal Container

svg_verify_icon = Image

lbl_verify_title, lbl_verify_dscr = Label

txtpcf_number_1 = Text Input

btnpcf_cancel_button, btnpcf_confirm_button = Button

YAML Output

⁠

Used Colours

Background - #FFFFFF

Font Colour - #314AA3

Icon Colour - #6087CC

Dscr Colour - #5E5B7B

⁠
