Font Slider

How to design it in Power Apps

Preview

⁠

⁠

What does it consist of?

1x Container

2x Image

1x Modern Slider

Procedure

Step 1 - create main container

Add a new Horizontal Container PCF, call it "font_slider" with this "DropShadow" property:

DropShadow.Semilight

Step 2 - create content

Add a new Image object, call it "paragraph_icon" with this "Image" property:


Add a new Text Slider PCF, call it "slider" with this "BasePaletteColor" property:

RGBA(78, 69, 221, 1)

Add a new Image object, call it "heading_icon" with this "Image" property:


This is an output:

⁠

⁠

How to use it via DesignKit

Prerequisites

the designed component according to the instructions from the previous section

Used Prefixes

horcont_font_slider = Horizontal Container

svg_paragraph_icon, svg_heading_icon = Image

slpcf_slider = Modern Slider

YAML Output

⁠

Used Colours

Container Colour - #FFFFFF

Slider Colour - #4E45DD

Slider Background Colour - #CDCDC9

⁠
