Cloud Pub/Sub

Pub/Sub is an asynchronous and scalable messaging service that decouples services producing messages from services processing those messages.

Pub/Sub allows services to communicate asynchronously, with latencies typically on the order of 100 milliseconds.

Pub/Sub is used for streaming analytics and data integration pipelines to load and distribute data. It's equally effective as a messaging-oriented middleware for service integration or as a queue to parallelize tasks.

Pub/Sub lets you create systems of event producers and consumers, called publishers and subscribers. Publishers communicate with subscribers asynchronously by broadcasting events, rather than by synchronous remote procedure calls (RPCs).

Publishers send events to the Pub/Sub service, without regard to how or when these events are to be processed. Pub/Sub then delivers events to all the services that react to them. In systems communicating through RPCs, publishers must wait for subscribers to receive the data. However, the asynchronous integration in Pub/Sub increases the flexibility and robustness of the overall system.

Common use cases

Ingesting user interaction and server events. To use user interaction events from end-user apps or server events from your system, you might forward them to Pub/Sub. You can then use a stream processing tool, such as Dataflow, which delivers the events to databases. Examples of such databases are BigQuery, Bigtable, and Cloud Storage. Pub/Sub lets you gather events from many clients simultaneously.

Real-time event distribution. Events, raw or processed, may be made available to multiple applications across your team and organization for real- time processing. Pub/Sub supports an "enterprise event bus" and event-driven application design patterns. Pub/Sub lets you integrate with many systems that export events to Pub/Sub.

Replicating data among databases. Pub/Sub is commonly used to distribute change events from databases. These events can be used to construct a view of the database state and state history in BigQuery and other data storage systems.

Parallel processing and workflows. You can efficiently distribute many tasks among multiple workers by using Pub/Sub messages to communicate with the workers. Examples of such tasks are compressing text files, sending email notifications, evaluating AI models, and reformatting images.

Enterprise event bus. You can create an enterprise-wide real-time data sharing bus, distributing business events, database updates, and analytics events across your organization.

Data streaming from applications, services, or IoT devices. For example, a SaaS application can publish a real-time feed of events. Or, a residential sensor can stream data to Pub/Sub for use in other Google Cloud products through a data-processing pipeline.

Refreshing distributed caches. For example, an application can publish invalidation events to update the IDs of objects that have changed.

Load balancing for reliability. For example, instances of a service may be deployed on Compute Engine in multiple zones but subscribe to a common topic. When the service fails in any zone, the others can pick up the load automatically.

Integrations

Pub/Sub has many integrations with other Google Cloud products to create a fully featured messaging system:

Stream processing and data integration. Supported by

Dataflow⁠

, including Dataflow

templates⁠

and

SQL⁠

, which allow processing and data integration into BigQuery and data lakes on Cloud Storage. Dataflow templates for moving data from Pub/Sub to Cloud Storage, BigQuery, and other products are available in the Pub/Sub and Dataflow UIs in the Google Cloud console. Integration with

Apache Spark⁠

, particularly when managed with

Dataproc⁠

is also available. Visual composition of integration and processing pipelines running on Spark + Dataproc can be accomplished with

Data Fusion⁠

Monitoring, Alerting and Logging. Supported by Monitoring and Logging products.

Authentication and IAM. Pub/Sub relies on a standard OAuth authentication used by other Google Cloud products and supports granular IAM, enabling access control for individual resources.

APIs. Pub/Sub uses standard

gRPC and REST service API technologies⁠

along with

client libraries⁠

for several languages.

Triggers, notifications, and webhooks. Pub/Sub offers push-based delivery of messages as HTTP POST requests to webhooks. You can implement workflow automation using

Cloud Functions⁠

or other serverless products.

Orchestration. Pub/Sub can be integrated into multistep serverless

Workflows⁠

declaratively. Big data and analytic orchestration often done with

Cloud Composer⁠

, which supports Pub/Sub triggers. You can also integrate Pub/Sub with

Application Integration⁠

(

Preview⁠

) which is an Integration-Platform-as-a-Service (iPaaS) solution. Application Integration provides a

Pub/Sub trigger⁠

to trigger or start integrations.

Integration Connectors.(

Preview⁠

) These

connectors⁠

let you connect to various data sources. With connectors, both Google Cloud services and third-party business applications are exposed to your integrations through a transparent, standard interface. For Pub/Sub, you can create a Pub/Sub

connection⁠

for use in your integrations.

⁠

Ref:

What is Pub/Sub? | Pub/Sub Documentation | Google Cloud⁠

⁠
