Design Process

Below is the design process for your outdoor design.

⁠

Design Approval

⁠

We offer this proposal, including all original concepts and designs, with the agreement that you will not share them publicly, on social media, or with outside contractors without the permission of Pratt Guys. We do encourage you to share the site internally with your family and friends and build excitement for your project!

⁠

Design Waivers

1️⃣ Color and Selection Waiver: The drawings' materials and colors are for conceptual purposes only and may not represent your final selections. The Material and Color Selection Finalization Form takes priority over any shown materials or colors. Please note that actual colors may vary from what is seen on monitors or when printed.

2️⃣ Landscape Waiver: Any landscaping depicted on renderings is for conceptual purposes only. Client must obtain landscape plan to verify specific plant species and sizes.

3️⃣ Special Features Waiver: Depictions of special features such as water and fire features are for conceptual purposes only. The velocity and volume of the water or fire will vary.

4️⃣ Engineering Waiver: Structural elements depicted on renderings are for conceptual purposes only. Engineering takes precedence over the size, location, and products used for structural masonry, wood framing, roofing, floors, etc.

⁠

Feasibility Study

Primary Structure Setbacks: 20’ Front, 5’ Sides, 10’ Rear Property Lines

Accessory Structure Setbacks: 5’ from Rear and Side Property Lines

Swimming Pool Setbacks: 5’ for Pool, 2’ for Equipment Pad

Max Lot Coverage by Impervious Surface Area: 65%

HOA Restrictions: N/A

⁠

Sun Study

The sun study below is to illustrate how shadows impact the project area throughout the year.

⁠

⁠

Design Overview

The drawings and renderings below reflect the design option chosen from the preliminary 2D sketches. There are two sets of renders, one set with the deck jets on the backside of the pool, one set with the deck jets on the house-side of the pool.

Scope

Pool

Sunshelf

LED Bubbler

Deck Jets (2)

Bench

Continuous Steps

Paver Deck

Planter Beds (Vegetation for Conceptual Purposes Only)

⁠

⁠

Renderings (Rear Deck Jets)

Below are 3D renderings of your chosen design layout with the deck jets on the backside of the pool. Click on any image to view gallery at full size.

There are no rows in this table

⁠

Renderings (Front Deck Jets)

Below are 3D renderings of your chosen design layout with the deck jets on the side of the pool closest to the house. Click on any image to view gallery at full size.

There are no rows in this table

⁠

360 Panoramic View

⁠

Loading…⁠

⁠

Archived Layouts (02/12/24)

Option 2

The second option still has a large planter along the street, and a smaller, though still large planter along the rear. Paver steppers with grass borders lead to the tanning ledge, situated on the backside of the pool. This layout also features a sunbathing area off the deep end.

⁠

⁠

Option 3

For the third option, the tanning ledge has been moved to the deep end, with the sunbathing area off the rear of the patio. The paver steppers leading to the sunbathing area in this option are lined with gravel. The pool deck has a little more space than Option 2, though less than in Option 1.

⁠

⁠

Option 4

The final layout also has the sunbathing are off the rear off the pool, pavers steppers leading to it on either side, and bordered with grass. The tanning ledge in this option spans the full width of the pool, and features continuous steps leading into the shallow end.

⁠
