Network Monitoring

February 12, 2021
After much encouragement from
The next step would be to generate the AWS architecture and connect the important actors together, this motivated me to study how could VPC and subnets be more intuitive.
VPC, subnets and route tables are simple rules that could evolve to pretty complex solutions.
Imagine if you could see the packages flowing through the VPC
Loading…
For this experiment, one screen hosts 4 subnets
Loading…
How many metrics can you recognize?
3 Hosts Dashbaord
Loading…
How many metrics can you recognize?
How about this version?
Loading…
Hosts Dashbaord (3).png
Loading…
Legend
⚪: read time
🏳️?🌈: processing time
🟢/🟡/🔴: status code and write time
First column total time < 100ms
Next 500ms
Next 1s
Next 2s
Last +5s
