Datasheet cabos


megaphone

Esta é uma página de auxílio para as tabelas de cálculo.

Descrição de Tipos de Cabos
Nome
Faixa de Frequência
Concatenacao
ATENUACAO_100m
Datasheet
⁠
@1/2" CELLFLEX-RFS
⁠
@150 MHz
⁠
⁠
2.66
⁠
@1/2" CELLFLEX-RFS
⁠
@174 MHz
⁠
⁠
2.87
⁠
@1/2" CELLFLEX-RFS
⁠
@200 MHz
⁠
⁠
3.08
⁠
@1/2" CELLFLEX-RFS
⁠
@300 MHz
⁠
⁠
3.81
⁠
@1/2" CELLFLEX-RFS
⁠
@400 MHz
⁠
⁠
4.43
⁠
@1/2" CELLFLEX-RFS
⁠
@450 MHz
⁠
⁠
4.71
⁠
@7/8" CELLFLEX-RFS
⁠
@150 MHz
⁠
⁠
1.39
⁠
@7/8" CELLFLEX-RFS
⁠
@174 MHz
⁠
⁠
1.5
⁠
@7/8" CELLFLEX-RFS
⁠
@200 MHz
⁠
⁠
1.62
⁠
@7/8" CELLFLEX-RFS
⁠
@300 MHz
⁠
⁠
2
⁠
@7/8" CELLFLEX-RFS
⁠
@400 MHz
⁠
⁠
2.32
⁠
@7/8" CELLFLEX-RFS
⁠
@450 MHz
⁠
⁠
2.47
⁠
@RG213 RGFLEX-RFS
⁠
@150 MHz
⁠
⁠
8.4
⁠
@RG213 RGFLEX-RFS
⁠
@174 MHz
⁠
⁠
9.1
⁠
@RG213 RGFLEX-RFS
⁠
@200 MHz
⁠
⁠
10.2
⁠
@RG213 RGFLEX-RFS
⁠
@300 MHz
⁠
⁠
12.3
⁠
@RG213 RGFLEX-RFS
⁠
@400 MHz
⁠
⁠
14.5
⁠
@RG213 RGFLEX-RFS
⁠
@450 MHz
⁠
⁠
15.5
⁠
@RG58-RFS
⁠
@150 MHz
⁠
⁠
19.2
⁠
@RG58-RFS
⁠
@174 MHz
⁠
⁠
22.4
⁠
@RG58-RFS
⁠
@200 MHz
⁠
⁠
24
⁠
@RG58-RFS
⁠
@300 MHz
⁠
⁠
29
⁠
@RG58-RFS
⁠
@400 MHz
⁠
⁠
34
⁠
@RG58-RFS
⁠
@450 MHz
⁠
⁠
36.2
There are no rows in this table
⁠
Faixa de Frequência
Faixa de Frequência
150 MHz
174 MHz
200 MHz
300 MHz
400 MHz
450 MHz
There are no rows in this table
⁠

Tipos de Cabos
Nome
1/2" CELLFLEX-RFS
7/8" CELLFLEX-RFS
RG213 RGFLEX-RFS
RG58-RFS
There are no rows in this table
⁠
