Hello! I'm Miguel Bastida, a skilled CNC machinist who brings unrivaled passion and expertise to every project.


Scroll down or navigate the menu (right) to see my skills ➡️
See my
Download my
resume
📄
About
🙋‍♂️
Coming soon: see my other design and manufacturing work

CNC Machining

With proficiency mostly in Haas machines, I excel in every aspect of machine operation: from building work-holding fixtures, seamless code transfer (CAM to postprocessor), to meticulous machine and tool setup/configuration for each unique job.
I am confident in my ability to write, inspect, and swiftly correct G code in real-time on the CNC integrated controller. Additionally, I keep myself up to date to maximize the potential of newly integrated G codes and all Haas new features.
When it comes to operating CNC machines, I prioritize both efficiency and safety. Adhering to best practices and safety standards, I create a secure work environment at all times.

This are the CNC machines I have experience with:
Haas 3 axis Mill
Haas 5 axis SS Mill
Haas Horizontal Mill
Haas Y axis lathe
Haas drill/tap mill
Okuma Multi axis lathe
DMG Mori 5 axis Mill
Rotary and Indexing heads



IMG_20190622_142613-ha editado-min.jpg

CAD & CAM


Proficient in SolidWorks (2016 and up)
Complex Assemblies
Top Down Design
Surfacing
Constrained Design
Blueprinting
Sheet Metal
Piping

Proficient Siemens NX (11 and up)
Complex Assemblies
Top Down Design
Constrained Design
Blueprinting
Surfacing
CAM
Simulation and inspection

Proficient in Mastercam (2017 and up)
Muti axis
Surfacing
Simulation and Is

Adept Creo Parametric (4.0 only)
Complex Assemblies
Top Down Design
Constrained Design

Some experience in BobCam (v30)

I have some experience using Autodesk Inventor, AutoCad, Fusion 360

Looking good so far? Let’s work together! You can reach me here

Email:

Metrology

Quick shop inspection (while setup on the machine) Quick shop inspection (while setup on the machine)
Quick shop inspection (while setup on the machine)
Toolroom and metrology lab inspection
Hardness and toughness testing
Sine inspection
CMM inspection (Zeiss Calypso)


Blueprinting

Complete assembly blueprinting
Engineering and machine shop annotations
WhatsApp Image 2023-08-31 at 10.13.14 PM.jpeg

GD&T (2009 & 2018)

When to use and when is cost effective to apply GD&T into a design
Rules of GD&T, when do they apply and when do they cancel each other
How to read, apply and draw GD&T into a blueprint
How to inspect manufactured pieces to GD&T specifications

Additive Manufacturing

CAD optimization for 3d printing
Model slicing
Hobbyist FDM machines
Formlabs SLA machine
Materials such as:
Nylon
Onyx (Nylon with chopped Carbon fiber)
Carbon Fiber Inlay Nylon
PLA
ABS
PEEK
Post processing:
Support removal
Washing
UV curing
Sanding

Manual Machining / Other Processes

Machining operations with:
Lathes
Milling Machines
Grinders (surface, bench)
Drill Press
Bandsaw
Heat Treatment (quenching, annealing, pack carburizing)
Toolmaking
Sandblasting
Polishing


Other Skills

project management
procuring
quoting
reports
collaborative work
office suite
presentations


Contact

Let’s team up and create precision masterpieces! You can reach me here

Email:
