G4S Mile API Documentation
G4S Mile API documentation
This is an API documentation to connect with our service. All responses and input body uses json format.
API KEY DEV
n09eDGTyunY56Xv88lcxj8ZL7MRSpERB
API ITEM
Mile API - Standard Documentation
GUARD NAME ID
GD11121314 - Guard 1
ITEM EXAMPLE
{
"itemRefId":"354tertwe4fg",
"itemBelongsTo":"alfa",
"itemStartTime":"2019-02-12 01:00:00",
"itemEndTime":"2019-02-13 01:00:00"
"orNumber": [
{
"id":"106610750966",
"listItemSubTitle": "106610750966"
},
{
"id":"106610750967",
"listItemSubTitle": "106610750967"
},
{
"id":"106610750968",
"listItemSubTitle": "106610750967"
},
{
"id":"106610750969",
"listItemSubTitle": "106610750967"
},
{
"id":"1066107509670",
"listItemSubTitle": "106610750967"
}
],
"sealBag":[
{
"id": ";104999808118",
"listItemSubTitle":"104999808118",
"bagSeal": "104999808118"
},
{
"id": "104999808119",
"listItemSubTitle":"104999808119",
"bagSeal": "104999808119"
},
{
"id": "104999808110",
"listItemSubTitle":"104999808110",
"bagSeal": "104999808110"
},
{
"id": "104999808111",
"listItemSubTitle":"104999808111",
"bagSeal": "104999808111"
},
{
"id": "104999808112",
"listItemSubTitle":"104999808112",
"bagSeal": "104999808112"
},
{
"id": "104999808113",
"listItemSubTitle":"104999808113",
"bagSeal": "104999808113"
},
{
"id": "104999808114",
"listItemSubTitle":"104999808114",
"bagSeal": "104999808114"
},
{
"id": "104999808115",
"listItemSubTitle":"104999808115",
"bagSeal": "104999808115"
},
{
"id": "104999808116",
"listItemSubTitle":"104999808116",
"bagSeal": "104999808116"
},
{
"id": "104999808117",
"listItemSubTitle":"104999808117",
"bagSeal": "104999808117"
},
{
"id": "104999808120",
"listItemSubTitle":"104999808120",
"bagSeal": "104999808120"
},
{
"id": "104999808121",
"listItemSubTitle":"104999808121",
"bagSeal": "104999808121"
},
{
"id": "104999808122",
"listItemSubTitle":"104999808122",
"bagSeal": "104999808122"
},
{
"id": "104999808123",
"listItemSubTitle":"104999808123",
"bagSeal": "104999808123"
},
{
"id": "104999808124",
"listItemSubTitle":"104999808124",
"bagSeal": "104999808124"
}
]
}
Specific Task Definition
Task : Start
ADDITIONAL REQUEST PARAM
Table 11
Param Name
Description
Data Type
Required
taskCaption
Text that will be displayed on the front list as caption
String
TRUE
taskTitle
Text that will be displayed on the frot list as title
String
TRUE
isStrict
If this field = true, then the task need to be done before the driver can access another task
Boolean
UserVar
Sub Field
Sub Description
runCode
to show run code
String
TRUE
vehicleNumber
to show vehicle number
String
TRUE
driverName
to show driver name
String
TRUE
custody1
to show custody name
String
TRUE
custody2
to show custody name 2
String
TRUE
phoneNumber
to activate the call function
String
TRUE
supply
Array of supply
Array
TRUE
bagSeal
array of bagseal to show seal number and client of the seal
Array
TRUE
vehicleCheckList
Array of vehicle check list
Array
TRUE
There are no rows in this table
4
Count
EXAMPLE
{
"flow": "start",
"taskStartTime":"2018-01-12 13:00:00",
"taskEndTime": "2019-12-12 13:00:00",
"taskOrder": 1,
"taskRefId":"44445",
"isStrict":true,
"taskCaption":"Start | 12:00 AM",
"taskTitle": "G4S Ciputat Office",
"taskSubTitle":"552199029470",
"taskAssignedTo":"username",
"UserVar": {
"locationId":"001",
"phoneNumber":"085712362647",
"runCode":"STS RUN 01",
"vehicleType":"Van",
"vehicleNumber":"142",
"vehicleLimit":"1.000.000.000",
"driverName":"Muhammad Alif Syafri",
"custody1":"Alfa Marzella",
"custody2":"Dika Maheswara",
"etoll":[
{
"id":"1242323432",
"listItemSubTitle":"1242323432",
"listItemContent":"Flazz BCA",
"sealEtoll":"10469697632",
